JSON messages

SessionClosed due to content policy violation

Description of the message: Emitted when content policy with termination action enabled is violated

Example message:

{"verdict":"TERMINATED","timestamp":"1568640063579","severity":"0","session_id":"svc-9S9nqpGqdns6GAJxULWjHp-my_connection-53","server_username":"root","server_port":"22","server_name":"server.acme.com","server_address":"10.170.255.206","protocol":"SSH","event_type_id":"449510124","event_name":"SessionClosed","connection_policy":"my_connection","client_port":"45946","client_name":"client.acme.com","client_address":"10.30.0.24","base_type_name":"meta","auth_method":"password","gateway_username":"gwtestauto"}

The message contains the following fields.

Field

Name

Scope

Present

base_type_name

Basic type

message

always

Description: basic message type: meta

Example: meta

Field

Name

Scope

Present

event_type_id

Signature ID

message

always

Description: numeric identifier of message type

Example: 449510124

Field

Name

Scope

Present

event_name

Event name

message

always

Description: the type of the message

Example: SessionClosed

Field

Name

Scope

Present

session_id

Session ID

session

always

Description: the unique identifier of the session

Example: svc-hjdBxA2UWkTadH3juDVwrT-my_connection-0

Field

Name

Scope

Present

severity

Severity

message

always

Description: number between 0-10 inclusive, equal to aggregated analytics score divided by 10 or 0 if analytics is disabled

Example: 0

Field

Name

Scope

Present

timestamp

Timestamp

message

always

Description: the UNIX time stamp when the event occurred

Example: 1554470652340

Field

Name

Scope

Present

server_username

Server user

session

always

Description: the server username

Example: root

Field

Name

Scope

Present

server_domain

Server user domain if known

session

sometimes

Description: the server domain, if known

Example: acme.com

Field

Name

Scope

Present

gateway_username

Gateway username

session

sometimes

Description: the authenticated gateway username if there was a successful gateway authentication

Example: gwtestauto

Field

Name

Scope

Present

gateway_domain

Gateway user domain

session

sometimes

Description: the authenticated gateway user domain if there was a successful gateway authentication and known

Example: acme.com

Field

Name

Scope

Present

server_name

Server name

session

always

Description: the server hostname or IP address if hostname is not known

Example: server.acme.com

Field

Name

Scope

Present

server_address

Server address

session

always

Description: the IP address of the server

Example: 10.170.255.206

Field

Name

Scope

Present

server_port

Server port

session

always

Description: the port number on the server

Example: 22

Field

Name

Scope

Present

client_name

Client name

session

always

Description: the client hostname or IP address if hostname is not known

Example: client.acme.com

Field

Name

Scope

Present

client_address

Client address

session

always

Description: the IP address of the client

Example: 10.30.0.24

Field

Name

Scope

Present

client_port

Client port

session

always

Description: the port number on the client

Example: 38014

Field

Name

Scope

Present

protocol

Application protocol

session

always

Description: SPS supported protocol

Example: SSH

Field

Name

Scope

Present

connection_policy

Connection policy name

session

always

Description: SPS connection policy name

Example: my_connection

Field

Name

Scope

Present

auth_method

Authentication method

session

always

Description: the type of authentication used in gateway authentication

Example: password

Field

Name

Scope

Present

verdict

Verdict

session

always

Description: describes how the session ended, e.g. ACCEPT, AUTH_FAIL, DENY, FAIL, TERMINATED

Example: TERMINATED

ChannelAlert triggered

Description of the message: Emitted when channel alert triggered by content policy

Example message:

{"event_type_id":"1244069864","event_name":"ChannelAlert","session_id":"svc-eyKp4M2pDBpbwHW4nCSe36-my_connection-14","severity":"0","timestamp":"1567509110329","server_username":"root", "gateway_username":"gwtestauto","server_name":"server.acme.com","server_address":"10.170.255.206","server_port":"22","client_name":"client.acme.com","client_address":"10.30.0.24","client_port":"56988","protocol":"SSH","connection_policy":"my_connection","base_type_name":"content_alert","alerting_type":"adp.event.command","matched_regexp":"sudo","matched_content":"sudo","rule_name":"PatternMatcherRule"}

The message contains the following fields.

Field

Name

Scope

Present

event_type_id

Signature ID

message

always

Description: numeric identifier of message type

Example: 1244069864

Field

Name

Scope

Present

event_name

Event name

message

always

Description: the type of the message

Example: ChannelAlert

Field

Name

Scope

Present

session_id

Session ID

session

always

Description: the unique identifier of the session

Example: svc-hjdBxA2UWkTadH3juDVwrT-my_connection-0

Field

Name

Scope

Present

severity

Severity

message

always

Description: number between 0-10 inclusive, equal to aggregated analytics score divided by 10 or 0 if analytics is disabled

Example: 0

Field

Name

Scope

Present

timestamp

Timestamp

message

always

Description: the UNIX time stamp when the event occurred

Example: 1554470652340

Field

Name

Scope

Present

server_username

Server user

session

always

Description: the server username

Example: root

Field

Name

Scope

Present

gateway_username

Gateway username

session

sometimes

Description: the authenticated gateway username if there was a successful gateway authentication

Example: gwtestauto

Field

Name

Scope

Present

server_name

Server name

session

always

Description: the server hostname or IP address if hostname is not known

Example: server.acme.com

Field

Name

Scope

Present

server_address

Server address

session

always

Description: the IP address of the server

Example: 10.170.255.206

Field

Name

Scope

Present

server_port

Server port

session

always

Description: the port number on the server

Example: 22

Field

Name

Scope

Present

client_name

Client name

session

always

Description: the client hostname or IP address if hostname is not known

Example: client.acme.com

Field

Name

Scope

Present

client_address

Client address

session

always

Description: the IP address of the client

Example: 10.30.0.24

Field

Name

Scope

Present

client_port

Client port

session

always

Description: the port number on the client

Example: 38014

Field

Name

Scope

Present

protocol

Application protocol

session

always

Description: SPS supported protocol

Example: SSH

Field

Name

Scope

Present

connection_policy

Connection policy name

session

always

Description: SPS connection policy name

Example: my_connection

Field

Name

Scope

Present

base_type_name

Basic type

message

always

Description: basic message type: content_alert

Example: content_alert

Field

Name

Scope

Present

alerting_type

Event type

message

sometimes

Description: the type of the event triggering the alert e.g. Command, Full screen content

Example: Command

Field

Name

Scope

Present

matched_regexp

Matched regexp

message

sometimes

Description: the regexp matching the content that triggered the alert

Example: sudo

Field

Name

Scope

Present

matched_content

Matched content

message

sometimes

Description: the screen content violating channel policy

Example: $ sudo

Field

Name

Scope

Present

rule_name

Reason

message

sometimes

Description: the rule triggering alert

Example: PatternMatcherRule

ServerConnect on initial contact

Description of the message: Emitted when SPS connects to the serverfor the first time in the session

Example message:

{"timestamp":"1557913242888","severity":"0","session_id":"svc-iiCfsG48oJG5smpuocBLAN-my_connection-43","server_port":"22","server_name":"server.acme.com","server_address":"10.170.255.206","protocol":"SSH","gateway_username":"gwtestauto","event_type_id":"107115592","event_name":"ServerConnect","connection_policy":"my_connection","client_port":"59190","client_name":"client.acme.com","client_address":"10.30.0.24","base_type_name":"meta"}

The message contains the following fields.

Field

Name

Scope

Present

base_type_name

Basic type

message

always

Description: basic message type: meta

Example: meta

Field

Name

Scope

Present

event_type_id

Signature ID

message

always

Description: numeric identifier of message type

Example: 107115592

Field

Name

Scope

Present

event_name

Event name

message

always

Description: the type of the message

Example: ServerConnect

Field

Name

Scope

Present

session_id

Session ID

session

always

Description: the unique identifier of the session

Example: svc-hjdBxA2UWkTadH3juDVwrT-my_connection-0

Field

Name

Scope

Present

severity

Severity

message

always

Description: number between 0-10 inclusive, equal to aggregated analytics score divided by 10 or 0 if analytics is disabled

Example: 0

Field

Name

Scope

Present

timestamp

Timestamp

message

always

Description: the UNIX time stamp when the event occurred

Example: 1554470652340

Field

Name

Scope

Present

gateway_username

Gateway username

session

sometimes

Description: the authenticated gateway username if there was a successful gateway authentication

Example: gwtestauto

Field

Name

Scope

Present

gateway_domain

Gateway user domain

session

sometimes

Description: the authenticated gateway user domain if there was a successful gateway authentication and known

Example: acme.com

Field

Name

Scope

Present

server_name

Server name

session

always

Description: the server hostname or IP address if hostname is not known

Example: server.acme.com

Field

Name

Scope

Present

server_address

Server address

session

always

Description: the IP address of the server

Example: 10.170.255.206

Field

Name

Scope

Present

server_port

Server port

session

always

Description: the port number on the server

Example: 22

Field

Name

Scope

Present

client_name

Client name

session

always

Description: the client hostname or IP address if hostname is not known

Example: client.acme.com

Field

Name

Scope

Present

client_address

Client address

session

always

Description: the IP address of the client

Example: 10.30.0.24

Field

Name

Scope

Present

client_port

Client port

session

always

Description: the port number on the client

Example: 38014

Field

Name

Scope

Present

protocol

Application protocol

session

always

Description: SPS supported protocol

Example: SSH

Field

Name

Scope

Present

connection_policy

Connection policy name

session

always

Description: SPS connection policy name

Example: my_connection

ServerConnect for secondary channels

Description of the message: Emitted when SPS connects to the serverfor opening further channels. The difference from initial connection is that the server user name is known and authenticated this time.

Example message:

{"timestamp":"1557913242888","severity":"0","session_id":"svc-iiCfsG48oJG5smpuocBLAN-my_connection-43","server_port":"22","server_name":"server.acme.com","server_address":"10.170.255.206","protocol":"SSH","gateway_username":"gwtestauto","event_type_id":"107115592","event_name":"ServerConnect","connection_policy":"my_connection","server_username":"root","client_port":"59190","client_name":"client.acme.com","client_address":"10.30.0.24","base_type_name":"meta"}

The message contains the following fields.

Field

Name

Scope

Present

base_type_name

Basic type

message

always

Description: basic message type: meta

Example: meta

Field

Name

Scope

Present

event_type_id

Signature ID

message

always

Description: numeric identifier of message type

Example: 107115592

Field

Name

Scope

Present

event_name

Event name

message

always

Description: the type of the message

Example: ServerConnect

Field

Name

Scope

Present

session_id

Session ID

session

always

Description: the unique identifier of the session

Example: svc-hjdBxA2UWkTadH3juDVwrT-my_connection-0

Field

Name

Scope

Present

severity

Severity

message

always

Description: number between 0-10 inclusive, equal to aggregated analytics score divided by 10 or 0 if analytics is disabled

Example: 0

Field

Name

Scope

Present

timestamp

Timestamp

message

always

Description: the UNIX time stamp when the event occurred

Example: 1554470652340

Field

Name

Scope

Present

server_username

Server user

session

always

Description: the server username

Example: root

Field

Name

Scope

Present

server_domain

Server user domain if known

session

sometimes

Description: the server domain, if known

Example: acme.com

Field

Name

Scope

Present

gateway_username

Gateway username

session

sometimes

Description: the authenticated gateway username if there was a successful gateway authentication

Example: gwtestauto

Field

Name

Scope

Present

gateway_domain

Gateway user domain

session

sometimes

Description: the authenticated gateway user domain if there was a successful gateway authentication and known

Example: acme.com

Field

Name

Scope

Present

server_name

Server name

session

always

Description: the server hostname or IP address if hostname is not known

Example: server.acme.com

Field

Name

Scope

Present

server_address

Server address

session

always

Description: the IP address of the server

Example: 10.170.255.206

Field

Name

Scope

Present

server_port

Server port

session

always

Description: the port number on the server

Example: 22

Field

Name

Scope

Present

client_name

Client name

session

always

Description: the client hostname or IP address if hostname is not known

Example: client.acme.com

Field

Name

Scope

Present

client_address

Client address

session

always

Description: the IP address of the client

Example: 10.30.0.24

Field

Name

Scope

Present

client_port

Client port

session

always

Description: the port number on the client

Example: 38014

Field

Name

Scope

Present

protocol

Application protocol

session

always

Description: SPS supported protocol

Example: SSH

Field

Name

Scope

Present

connection_policy

Connection policy name

session

always

Description: SPS connection policy name

Example: my_connection

ServerAuthenticationSuccess

Description of the message: Emitted after the server authentication successfully happened

Example message:

{"timestamp":"1557913243423","severity":"0","session_id":"svc-iiCfsG48oJG5smpuocBLAN-my_connection-43","server_username":"root","server_port":"22","server_name":"server.acme.com","server_address":"10.170.255.206","protocol":"SSH","gateway_username":"gwtestauto","event_type_id":"1865245228","event_name":"ServerAuthenticationSuccess","connection_policy":"my_connection","client_port":"59190","client_name":"client.acme.com","client_address":"10.30.0.24","base_type_name":"meta"}

The message contains the following fields.

Field

Name

Scope

Present

base_type_name

Basic type

message

always

Description: basic message type: meta

Example: meta

Field

Name

Scope

Present

event_type_id

Signature ID

message

always

Description: numeric identifier of message type

Example: 1865245228

Field

Name

Scope

Present

event_name

Event name

message

always

Description: the type of the message

Example: ServerAuthenticationSuccess

Field

Name

Scope

Present

session_id

Session ID

session

always

Description: the unique identifier of the session

Example: svc-hjdBxA2UWkTadH3juDVwrT-my_connection-0

Field

Name

Scope

Present

severity

Severity

message

always

Description: number between 0-10 inclusive, equal to aggregated analytics score divided by 10 or 0 if analytics is disabled

Example: 0

Field

Name

Scope

Present

timestamp

Timestamp

message

always

Description: the UNIX time stamp when the event occurred

Example: 1554470652340

Field

Name

Scope

Present

server_username

Server user

session

always

Description: the server username

Example: root

Field

Name

Scope

Present

server_domain

Server user domain if known

session

sometimes

Description: the server domain, if known

Example: acme.com

Field

Name

Scope

Present

gateway_username

Gateway username

session

sometimes

Description: the authenticated gateway username if there was a successful gateway authentication

Example: gwtestauto

Field

Name

Scope

Present

gateway_domain

Gateway user domain

session

sometimes

Description: the authenticated gateway user domain if there was a successful gateway authentication and known

Example: acme.com

Field

Name

Scope

Present

server_name

Server name

session

always

Description: the server hostname or IP address if hostname is not known

Example: server.acme.com

Field

Name

Scope

Present

server_address

Server address

session

always

Description: the IP address of the server

Example: 10.170.255.206

Field

Name

Scope

Present

server_port

Server port

session

always

Description: the port number on the server

Example: 22

Field

Name

Scope

Present

client_name

Client name

session

always

Description: the client hostname or IP address if hostname is not known

Example: client.acme.com

Field

Name

Scope

Present

client_address

Client address

session

always

Description: the IP address of the client

Example: 10.30.0.24

Field

Name

Scope

Present

client_port

Client port

session

always

Description: the port number on the client

Example: 38014

Field

Name

Scope

Present

protocol

Application protocol

session

always

Description: SPS supported protocol

Example: SSH

Field

Name

Scope

Present

connection_policy

Connection policy name

session

always

Description: SPS connection policy name

Example: my_connection

ServerAuthenticationFailure

Description of the message: Emitted after the server authentication failed

Example message:

{"timestamp":"1557913134598","severity":"0","session_id":"svc-iiCfsG48oJG5smpuocBLAN-my_connection-33","server_username":"root","server_port":"22","server_name":"server.acme.com","server_address":"10.170.255.206","protocol":"SSH","gateway_username":"gwtestauto","event_type_id":"1262825953","event_name":"ServerAuthenticationFailure","connection_policy":"my_connection","client_port":"56692","client_name":"client.acme.com","client_address":"10.30.0.24","base_type_name":"meta"}

The message contains the following fields.

Field

Name

Scope

Present

base_type_name

Basic type

message

always

Description: basic message type: meta

Example: meta

Field

Name

Scope

Present

event_type_id

Signature ID

message

always

Description: numeric identifier of message type

Example: 1262825953

Field

Name

Scope

Present

event_name

Event name

message

always

Description: the type of the message

Example: ServerAuthenticationFailure

Field

Name

Scope

Present

session_id

Session ID

session

always

Description: the unique identifier of the session

Example: svc-hjdBxA2UWkTadH3juDVwrT-my_connection-0

Field

Name

Scope

Present

severity

Severity

message

always

Description: number between 0-10 inclusive, equal to aggregated analytics score divided by 10 or 0 if analytics is disabled

Example: 0

Field

Name

Scope

Present

timestamp

Timestamp

message

always

Description: the UNIX time stamp when the event occurred

Example: 1554470652340

Field

Name

Scope

Present

server_username

Server user

session

always

Description: contains the non authenticated server username

Example: root

Field

Name

Scope

Present

server_domain

Server user domain if known

session

sometimes

Description: the non authenticated server domain, if known

Example: acme.com

Field

Name

Scope

Present

gateway_username

Gateway username

session

sometimes

Description: the authenticated gateway username if there was a successful gateway authentication

Example: gwtestauto

Field

Name

Scope

Present

gateway_domain

Gateway user domain

session

sometimes

Description: the authenticated gateway user domain if there was a successful gateway authentication and known

Example: acme.com

Field

Name

Scope

Present

server_name

Server name

session

always

Description: the server hostname or IP address if hostname is not known

Example: server.acme.com

Field

Name

Scope

Present

server_address

Server address

session

always

Description: the IP address of the server

Example: 10.170.255.206

Field

Name

Scope

Present

server_port

Server port

session

always

Description: the port number on the server

Example: 22

Field

Name

Scope

Present

client_name

Client name

session

always

Description: the client hostname or IP address if hostname is not known

Example: client.acme.com

Field

Name

Scope

Present

client_address

Client address

session

always

Description: the IP address of the client

Example: 10.30.0.24

Field

Name

Scope

Present

client_port

Client port

session

always

Description: the port number on the client

Example: 38014

Field

Name

Scope

Present

protocol

Application protocol

session

always

Description: SPS supported protocol

Example: SSH

Field

Name

Scope

Present

connection_policy

Connection policy name

session

always

Description: SPS connection policy name

Example: my_connection

GatewayAuthenticationFailure

Description of the message: Emitted after a failed gateway authentication. Note that the gateway username here is not authenticated and will not be retained in further messages to avoid confusion with an authenticated gateway user.

Example message:

{"timestamp":"1557913110027","severity":"0","session_id":"svc-iiCfsG48oJG5smpuocBLAN-my_connection-31","protocol":"SSH","gateway_username":"gwtestauto","event_type_id":"1843867026","event_name":"GatewayAuthenticationFailure","connection_policy":"my_connection","client_port":"56020","client_name":"client.acme.com","client_address":"10.30.0.24","base_type_name":"meta"}

The message contains the following fields.

Field

Name

Scope

Present

base_type_name

Basic type

message

always

Description: basic message type: meta

Example: meta

Field

Name

Scope

Present

event_type_id

Signature ID

message

always

Description: numeric identifier of message type

Example: 1843867026

Field

Name

Scope

Present

event_name

Event name

message

always

Description: the type of the message

Example: GatewayAuthenticationFailure

Field

Name

Scope

Present

session_id

Session ID

session

always

Description: the unique identifier of the session

Example: svc-hjdBxA2UWkTadH3juDVwrT-my_connection-0

Field

Name

Scope

Present

severity

Severity

message

always

Description: number between 0-10 inclusive, equal to aggregated analytics score divided by 10 or 0 if analytics is disabled

Example: 0

Field

Name

Scope

Present

timestamp

Timestamp

message

always

Description: the UNIX time stamp when the event occurred

Example: 1554470652340

Field

Name

Scope

Present

gateway_username

Gateway username

message

always

Description: the non authenticated gateway username

Example: gwtestauto

Field

Name

Scope

Present

gateway_username

Gateway user domain

session

sometimes

Description: the non authenticated gateway user domain if known

Example: acme.com

Field

Name

Scope

Present

client_name

Client name

session

always

Description: the client hostname or IP address if hostname is not known

Example: client.acme.com

Field

Name

Scope

Present

client_address

Client address

session

always

Description: the IP address of the client

Example: 10.30.0.24

Field

Name

Scope

Present

client_port

Client port

session

always

Description: the port number on the client

Example: 38014

Field

Name

Scope

Present

protocol

Application protocol

session

always

Description: SPS supported protocol

Example: SSH

Field

Name

Scope

Present

connection_policy

Connection policy name

session

always

Description: SPS connection policy name

Example: my_connection

SessionClosed of successfully authenticated session

Description of the message: Emitted when the session ends and server authentication and any gateway authentication was successful. There may be further messages related to the session after this message due to post processing of session data!

Example message:

{"timestamp":"1557912701233","severity":"0","session_id":"svc-mBbMWzauBWHQN9TpoZz8mD-my_connection-6","server_username":"root","server_port":"22","server_name":"server.acme.com","server_address":"10.170.255.206","protocol":"SSH","gateway_username":"gwtestauto","event_type_id":"449510124","event_name":"SessionClosed","connection_policy":"my_connection","client_port":"46958","client_name":"client.acme.com","client_address":"10.30.0.24","base_type_name":"meta","auth_method":"password","verdict":"ACCEPT"}

The message contains the following fields.

Field

Name

Scope

Present

base_type_name

Basic type

message

always

Description: basic message type: meta

Example: meta

Field

Name

Scope

Present

event_type_id

Signature ID

message

always

Description: numeric identifier of message type

Example: 449510124

Field

Name

Scope

Present

event_name

Event name

message

always

Description: the type of the message

Example: SessionClosed

Field

Name

Scope

Present

session_id

Session ID

session

always

Description: the unique identifier of the session

Example: svc-hjdBxA2UWkTadH3juDVwrT-my_connection-0

Field

Name

Scope

Present

severity

Severity

message

always

Description: number between 0-10 inclusive, equal to aggregated analytics score divided by 10 or 0 if analytics is disabled

Example: 0

Field

Name

Scope

Present

timestamp

Timestamp

message

always

Description: the UNIX time stamp when the event occurred

Example: 1554470652340

Field

Name

Scope

Present

server_username

Server user

session

always

Description: the server username

Example: root

Field

Name

Scope

Present

server_domain

Server user domain if known

session

sometimes

Description: the server domain, if known

Example: acme.com

Field

Name

Scope

Present

gateway_username

Gateway username

session

sometimes

Description: the authenticated gateway username if there was a successful gateway authentication

Example: gwtestauto

Field

Name

Scope

Present

gateway_domain

Gateway user domain

session

sometimes

Description: the authenticated gateway user domain if there was a successful gateway authentication and known

Example: acme.com

Field

Name

Scope

Present

server_name

Server name

session

always

Description: the server hostname or IP address if hostname is not known

Example: server.acme.com

Field

Name

Scope

Present

server_address

Server address

session

always

Description: the IP address of the server

Example: 10.170.255.206

Field

Name

Scope

Present

server_port

Server port

session

always

Description: the port number on the server

Example: 22

Field

Name

Scope

Present

client_name

Client name

session

always

Description: the client hostname or IP address if hostname is not known

Example: client.acme.com

Field

Name

Scope

Present

client_address

Client address

session

always

Description: the IP address of the client

Example: 10.30.0.24

Field

Name

Scope

Present

client_port

Client port

session

always

Description: the port number on the client

Example: 38014

Field

Name

Scope

Present

protocol

Application protocol

session

always

Description: SPS supported protocol

Example: SSH

Field

Name

Scope

Present

connection_policy

Connection policy name

session

always

Description: SPS connection policy name

Example: my_connection

Field

Name

Scope

Present

auth_method

Authentication method

session

always

Description: the type of authentication used in gateway authentication

Example: password

Field

Name

Scope

Present

verdict

Verdict

session

always

Description: describes how the session ended, e.g. ACCEPT, AUTH_FAIL, DENY, FAIL, TERMINATED

Example: ACCEPT

SessionClosed after a failed gateway authentication

Description of the message: Emitted when the session ends because gateway authentication failed.

Example message:

{"timestamp":"1557912725391","severity":"0","session_id":"svc-mBbMWzauBWHQN9TpoZz8mD-my_connection-9","protocol":"SSH","event_type_id":"449510124","event_name":"SessionClosed","connection_policy":"my_connection","client_port":"47444","client_name":"client.acme.com","client_address":"10.30.0.24","base_type_name":"meta","verdict":"AUTH_FAIL"}

The message contains the following fields.

Field

Name

Scope

Present

base_type_name

Basic type

message

always

Description: basic message type: meta

Example: meta

Field

Name

Scope

Present

event_type_id

Signature ID

message

always

Description: numeric identifier of message type

Example: 449510124

Field

Name

Scope

Present

event_name

Event name

message

always

Description: the type of the message

Example: SessionClosed

Field

Name

Scope

Present

session_id

Session ID

session

always

Description: the unique identifier of the session

Example: svc-hjdBxA2UWkTadH3juDVwrT-my_connection-0

Field

Name

Scope

Present

severity

Severity

message

always

Description: number between 0-10 inclusive, equal to aggregated analytics score divided by 10 or 0 if analytics is disabled

Example: 0

Field

Name

Scope

Present

timestamp

Timestamp

message

always

Description: the UNIX time stamp when the event occurred

Example: 1554470652340

Field

Name

Scope

Present

client_name

Client name

session

always

Description: the client hostname or IP address if hostname is not known

Example: client.acme.com

Field

Name

Scope

Present

client_address

Client address

session

always

Description: the IP address of the client

Example: 10.30.0.24

Field

Name

Scope

Present

client_port

Client port

session

always

Description: the port number on the client

Example: 38014

Field

Name

Scope

Present

protocol

Application protocol

session

always

Description: SPS supported protocol

Example: SSH

Field

Name

Scope

Present

connection_policy

Connection policy name

session

always

Description: SPS connection policy name

Example: my_connection

Field

Name

Scope

Present

verdict

Verdict

session

always

Description: describes how the session ended, e.g. ACCEPT, AUTH_FAIL, DENY, FAIL, TERMINATED

Example: AUTH_FAIL

SessionClosed after a failed server authentication

Description of the message: Emitted when the session ends because server authentication failed.

Example message:

{"timestamp":"1557912748990","severity":"0","session_id":"svc-mBbMWzauBWHQN9TpoZz8mD-my_connection-11","verdict":"AUTH_FAIL","server_port":"22","server_name":"server.acme.com","server_address":"10.170.255.206","protocol":"SSH","gateway_username":"gwtestauto","event_type_id":"449510124","event_name":"SessionClosed","connection_policy":"my_connection","client_port":"47840","client_name":"client.acme.com","client_address":"10.30.0.24","base_type_name":"meta"}

The message contains the following fields.

Field

Name

Scope

Present

base_type_name

Basic type

message

always

Description: basic message type: meta

Example: meta

Field

Name

Scope

Present

event_type_id

Signature ID

message

always

Description: numeric identifier of message type

Example: 449510124

Field

Name

Scope

Present

event_name

Event name

message

always

Description: the type of the message

Example: SessionClosed

Field

Name

Scope

Present

session_id

Session ID

session

always

Description: the unique identifier of the session

Example: svc-hjdBxA2UWkTadH3juDVwrT-my_connection-0

Field

Name

Scope

Present

severity

Severity

message

always

Description: number between 0-10 inclusive, equal to aggregated analytics score divided by 10 or 0 if analytics is disabled

Example: 0

Field

Name

Scope

Present

timestamp

Timestamp

message

always

Description: the UNIX time stamp when the event occurred

Example: 1554470652340

Field

Name

Scope

Present

gateway_username

Gateway username

session

sometimes

Description: the authenticated gateway username if there was a successful gateway authentication

Example: gwtestauto

Field

Name

Scope

Present

gateway_domain

Gateway user domain

session

sometimes

Description: the authenticated gateway user domain if there was a successful gateway authentication and known

Example: acme.com

Field

Name

Scope

Present

server_name

Server name

session

always

Description: the server hostname or IP address if hostname is not known

Example: server.acme.com

Field

Name

Scope

Present

server_address

Server address

session

always

Description: the IP address of the server

Example: 10.170.255.206

Field

Name

Scope

Present

server_port

Server port

session

always

Description: the port number on the server

Example: 22

Field

Name

Scope

Present

client_name

Client name

session

always

Description: the client hostname or IP address if hostname is not known

Example: client.acme.com

Field

Name

Scope

Present

client_address

Client address

session

always

Description: the IP address of the client

Example: 10.30.0.24

Field

Name

Scope

Present

client_port

Client port

session

always

Description: the port number on the client

Example: 38014

Field

Name

Scope

Present

protocol

Application protocol

session

always

Description: SPS supported protocol

Example: SSH

Field

Name

Scope

Present

connection_policy

Connection policy name

session

always

Description: SPS connection policy name

Example: my_connection

Field

Name

Scope

Present

verdict

Verdict

session

always

Description: describes how the session ended, e.g. ACCEPT, AUTH_FAIL, DENY, FAIL, TERMINATED

Example: AUTH_FAIL

RdpEmbeddedInTsg

Description of the message: Emitted when the gateway user is acquired in a Terminal Service Gateway authentication scenario.

Example message:

{"timestamp":"1558007294417","severity":"0","session_id":"svc-oUDm7arcL8zNb3t2CVwSQr-my_connection-50-4","protocol":"RDP","gateway_username":"gwtestauto","event_type_id":"998298775","event_name":"RdpEmbeddedInTsg","connection_policy":"my_connection","client_port":"51270","client_name":"client.acme.com","client_address":"10.30.0.24","base_type_name":"meta"}

The message contains the following fields.

Field

Name

Scope

Present

base_type_name

Basic type

message

always

Description: basic message type: meta

Example: meta

Field

Name

Scope

Present

event_type_id

Signature ID

message

always

Description: numeric identifier of message type

Example: 998298775

Field

Name

Scope

Present

event_name

Event name

message

always

Description: the type of the message

Example: RdpEmbeddedInTsg

Field

Name

Scope

Present

session_id

Session ID

session

always

Description: the unique identifier of the session

Example: svc-hjdBxA2UWkTadH3juDVwrT-my_connection-0

Field

Name

Scope

Present

severity

Severity

message

always

Description: number between 0-10 inclusive, equal to aggregated analytics score divided by 10 or 0 if analytics is disabled

Example: 0

Field

Name

Scope

Present

timestamp

Timestamp

message

always

Description: the UNIX time stamp when the event occurred

Example: 1554470652340

Field

Name

Scope

Present

gateway_username

Gateway username

session

always

Description: the authenticated gateway username

Example: gwtestauto

Field

Name

Scope

Present

client_name

Client name

session

always

Description: the client hostname or IP address if hostname is not known

Example: client.acme.com

Field

Name

Scope

Present

client_address

Client address

session

always

Description: the IP address of the client

Example: 10.30.0.24

Field

Name

Scope

Present

client_port

Client port

session

always

Description: the port number on the client

Example: 38014

Field

Name

Scope

Present

protocol

Application protocol

session

always

Description: SPS supported protocol

Example: SSH

Field

Name

Scope

Present

connection_policy

Connection policy name

session

always

Description: SPS connection policy name

Example: my_connection

SessionScored

Description of the message: Score messages represent scoring events when SPS has calculated an initial or changed score for the session.

Example message:

{"timestamp":"1558009822701","severity":"7","session_id":"svc-62a6XGcPzaFvLYDhVYDYXj-my_connection-0","server_username":"root","server_port":"22","server_name":"server.acme.com","server_address":"10.170.255.206","protocol":"SSH","gateway_username":"gwtestauto","event_type_id":"1991765353","event_name":"SessionScored","connection_policy":"my_connection","client_port":"35620","client_name":"client.acme.com","client_address":"10.30.0.24","base_type_name":"score","algorithm_score":"18","algorithm_name":"keystroke","aggregated_score":"70"}

The message contains the following fields.

Field

Name

Scope

Present

base_type_name

Basic type

message

always

Description: basic message type: score

Example: score

Field

Name

Scope

Present

event_type_id

Signature ID

message

always

Description: numeric identifier of message type

Example: 1991765353

Field

Name

Scope

Present

event_name

Event name

message

always

Description: the type of the message

Example: SessionScored

Field

Name

Scope

Present

session_id

Session ID

session

always

Description: the unique identifier of the session

Example: svc-hjdBxA2UWkTadH3juDVwrT-my_connection-0

Field

Name

Scope

Present

severity

Severity

message

always

Description: number between 0-10 inclusive, equal to aggregated analytics score divided by 10 or 0 if analytics is disabled

Example: 0

Field

Name

Scope

Present

timestamp

Timestamp

message

always

Description: the UNIX time stamp when the event occurred

Example: 1554470652340

Field

Name

Scope

Present

server_username

Server user

session

always

Description: the server username

Example: root

Field

Name

Scope

Present

server_domain

Server user domain if known

session

sometimes

Description: the server domain, if known

Example: acme.com

Field

Name

Scope

Present

gateway_username

Gateway username

session

sometimes

Description: the authenticated gateway username if there was a successful gateway authentication

Example: gwtestauto

Field

Name

Scope

Present

gateway_domain

Gateway user domain

session

sometimes

Description: the authenticated gateway user domain if there was a successful gateway authentication and known

Example: acme.com

Field

Name

Scope

Present

server_name

Server name

session

always

Description: the server hostname or IP address if hostname is not known

Example: server.acme.com

Field

Name

Scope

Present

server_address

Server address

session

always

Description: the IP address of the server

Example: 10.170.255.206

Field

Name

Scope

Present

server_port

Server port

session

always

Description: the port number on the server

Example: 22

Field

Name

Scope

Present

client_name

Client name

session

always

Description: the client hostname or IP address if hostname is not known

Example: client.acme.com

Field

Name

Scope

Present

client_address

Client address

session

always

Description: the IP address of the client

Example: 10.30.0.24

Field

Name

Scope

Present

client_port

Client port

session

always

Description: the port number on the client

Example: 38014

Field

Name

Scope

Present

protocol

Application protocol

session

always

Description: SPS supported protocol

Example: SSH

Field

Name

Scope

Present

connection_policy

Connection policy name

session

always

Description: SPS connection policy name

Example: my_connection

Field

Name

Scope

Present

aggregated_score

Aggregated score

message

always

Description: the average score from all enabled analytics algorithms

Example: 50

Field

Name

Scope

Present

algorithm_name

Algorithm name

message

always

Description: the name of the algorithm that changed value

Example: keystroke

Field

Name

Scope

Present

algorithm_score

Algorithm score

message

always

Description: the new score value of the algorithm that changed value

Example: 60

CommandChannelEvent

Description of the message: Emitted when a command is detected in the session channel text.

Example message:

{"timestamp":"1557912701166","severity":"0","session_id":"svc-mBbMWzauBWHQN9TpoZz8mD-my_connection-6","server_username":"root","server_port":"22","server_name":"server.acme.com","server_address":"10.170.255.206","protocol":"SSH","gateway_username":"gwtestauto","event_type_id":"127084214","event_name":"CommandChannelEvent","connection_policy":"my_connection","command":"exit","client_port":"46958","client_name":"client.acme.com","client_address":"10.30.0.24","base_type_name":"content"}

The message contains the following fields.

Field

Name

Scope

Present

base_type_name

Basic type

message

always

Description: basic message type: content

Example: content

Field

Name

Scope

Present

event_type_id

Signature ID

message

always

Description: numeric identifier of message type

Example: 127084214

Field

Name

Scope

Present

event_name

Event name

message

always

Description: the type of the message

Example: CommandChannelEvent

Field

Name

Scope

Present

session_id

Session ID

session

always

Description: the unique identifier of the session

Example: svc-hjdBxA2UWkTadH3juDVwrT-my_connection-0

Field

Name

Scope

Present

severity

Severity

message

always

Description: number between 0-10 inclusive, equal to aggregated analytics score divided by 10 or 0 if analytics is disabled

Example: 0

Field

Name

Scope

Present

timestamp

Timestamp

message

always

Description: the UNIX time stamp when the event occurred

Example: 1554470652340

Field

Name

Scope

Present

server_username

Server user

session

always

Description: the server username

Example: root

Field

Name

Scope

Present

server_domain

Server user domain if known

session

sometimes

Description: the server domain, if known

Example: acme.com

Field

Name

Scope

Present

gateway_username

Gateway username

session

sometimes

Description: the authenticated gateway username if there was a successful gateway authentication

Example: gwtestauto

Field

Name

Scope

Present

gateway_domain

Gateway user domain

session

sometimes

Description: the authenticated gateway user domain if there was a successful gateway authentication and known

Example: acme.com

Field

Name

Scope

Present

server_name

Server name

session

always

Description: the server hostname or IP address if hostname is not known

Example: server.acme.com

Field

Name

Scope

Present

server_address

Server address

session

always

Description: the IP address of the server

Example: 10.170.255.206

Field

Name

Scope

Present

server_port

Server port

session

always

Description: the port number on the server

Example: 22

Field

Name

Scope

Present

client_name

Client name

session

always

Description: the client hostname or IP address if hostname is not known

Example: client.acme.com

Field

Name

Scope

Present

client_address

Client address

session

always

Description: the IP address of the client

Example: 10.30.0.24

Field

Name

Scope

Present

client_port

Client port

session

always

Description: the port number on the client

Example: 38014

Field

Name

Scope

Present

protocol

Application protocol

session

always

Description: SPS supported protocol

Example: SSH

Field

Name

Scope

Present

connection_policy

Connection policy name

session

always

Description: SPS connection policy name

Example: my_connection

Field

Name

Scope

Present

command

Command

message

always

Description: the full command detected

Example: exit

WindowTitleChannelEvent

Description of the message: Emitted when a command is detected in the session channel text.

Example message:

{"window_title":"Shortcut Tools Application Tools Administrative Tools","timestamp":"1558007305516","severity":"0","session_id":"svc-oUDm7arcL8zNb3t2CVwSQr-my_connection-50-4","server_username":"Administrator","server_port":"3389","server_name":"server.acme.com","server_address":"10.170.255.206","protocol":"RDP","gateway_username":"gwtestauto","event_type_id":"911383355","event_name":"WindowTitleChannelEvent","connection_policy":"my_connection","client_port":"51270","client_name":"client.acme.com","client_address":"10.30.0.24","base_type_name":"content"}

The message contains the following fields.

Field

Name

Scope

Present

base_type_name

Basic type

message

always

Description: basic message type: content

Example: content

Field

Name

Scope

Present

event_type_id

Signature ID

message

always

Description: numeric identifier of message type

Example: 911383355

Field

Name

Scope

Present

event_name

Event name

message

always

Description: the type of the message

Example: WindowTitleChannelEvent

Field

Name

Scope

Present

session_id

Session ID

session

always

Description: the unique identifier of the session

Example: svc-hjdBxA2UWkTadH3juDVwrT-my_connection-0

Field

Name

Scope

Present

severity

Severity

message

always

Description: number between 0-10 inclusive, equal to aggregated analytics score divided by 10 or 0 if analytics is disabled

Example: 0

Field

Name

Scope

Present

timestamp

Timestamp

message

always

Description: the UNIX time stamp when the event occurred

Example: 1554470652340

Field

Name

Scope

Present

server_username

Server user

session

always

Description: the server username

Example: root

Field

Name

Scope

Present

server_domain

Server user domain if known

session

sometimes

Description: the server domain, if known

Example: acme.com

Field

Name

Scope

Present

gateway_username

Gateway username

session

sometimes

Description: the authenticated gateway username if there was a successful gateway authentication

Example: gwtestauto

Field

Name

Scope

Present

gateway_domain

Gateway user domain

session

sometimes

Description: the authenticated gateway user domain if there was a successful gateway authentication and known

Example: acme.com

Field

Name

Scope

Present

server_name

Server name

session

always

Description: the server hostname or IP address if hostname is not known

Example: server.acme.com

Field

Name

Scope

Present

server_address

Server address

session

always

Description: the IP address of the server

Example: 10.170.255.206

Field

Name

Scope

Present

server_port

Server port

session

always

Description: the port number on the server

Example: 22

Field

Name

Scope

Present

client_name

Client name

session

always

Description: the client hostname or IP address if hostname is not known

Example: client.acme.com

Field

Name

Scope

Present

client_address

Client address

session

always

Description: the IP address of the client

Example: 10.30.0.24

Field

Name

Scope

Present

client_port

Client port

session

always

Description: the port number on the client

Example: 38014

Field

Name

Scope

Present

protocol

Application protocol

session

always

Description: SPS supported protocol

Example: SSH

Field

Name

Scope

Present

connection_policy

Connection policy name

session

always

Description: SPS connection policy name

Example: my_connection

Field

Name

Scope

Present

window_title

Window title

message

always

Description: the window title detected in graphical protocol

Example: firefox

FileTransfer

Description of the message: Emitted when a command is detected in the session channel text.

Example message:

{"timestamp":"1558023671115","severity":"0","session_id":"svc-2L83Phh9J6GKLWTc881awk-my_connection-316","server_username":"root","server_port":"22","server_name":"server.acme.com","server_address":"10.170.255.206","protocol":"SSH","gateway_username":"gwtestauto","filepath":"","filename":"cpuinfo","file_operation":"UPLOAD","event_type_id":"1127618380","event_name":"FileTransfer","connection_policy":"my_connection","client_port":"44292","client_name":"client.acme.com","client_address":"10.30.0.24","base_type_name":"content"}

The message contains the following fields.

Field

Name

Scope

Present

base_type_name

Basic type

message

always

Description: basic message type: content

Example: content

Field

Name

Scope

Present

event_type_id

Signature ID

message

always

Description: numeric identifier of message type

Example: 1127618380

Field

Name

Scope

Present

event_name

Event name

message

always

Description: the type of the message

Example: FileTransfer

Field

Name

Scope

Present

session_id

Session ID

session

always

Description: the unique identifier of the session

Example: svc-hjdBxA2UWkTadH3juDVwrT-my_connection-0

Field

Name

Scope

Present

severity

Severity

message

always

Description: number between 0-10 inclusive, equal to aggregated analytics score divided by 10 or 0 if analytics is disabled

Example: 0

Field

Name

Scope

Present

timestamp

Timestamp

message

always

Description: the UNIX time stamp when the event occurred

Example: 1554470652340

Field

Name

Scope

Present

server_username

Server user

session

always

Description: the server username

Example: root

Field

Name

Scope

Present

server_domain

Server user domain if known

session

sometimes

Description: the server domain, if known

Example: acme.com

Field

Name

Scope

Present

gateway_username

Gateway username

session

sometimes

Description: the authenticated gateway username if there was a successful gateway authentication

Example: gwtestauto

Field

Name

Scope

Present

gateway_domain

Gateway user domain

session

sometimes

Description: the authenticated gateway user domain if there was a successful gateway authentication and known

Example: acme.com

Field

Name

Scope

Present

server_name

Server name

session

always

Description: the server hostname or IP address if hostname is not known

Example: server.acme.com

Field

Name

Scope

Present

server_address

Server address

session

always

Description: the IP address of the server

Example: 10.170.255.206

Field

Name

Scope

Present

server_port

Server port

session

always

Description: the port number on the server

Example: 22

Field

Name

Scope

Present

client_name

Client name

session

always

Description: the client hostname or IP address if hostname is not known

Example: client.acme.com

Field

Name

Scope

Present

client_address

Client address

session

always

Description: the IP address of the client

Example: 10.30.0.24

Field

Name

Scope

Present

client_port

Client port

session

always

Description: the port number on the client

Example: 38014

Field

Name

Scope

Present

protocol

Application protocol

session

always

Description: SPS supported protocol

Example: SSH

Field

Name

Scope

Present

connection_policy

Connection policy name

session

always

Description: SPS connection policy name

Example: my_connection

Field

Name

Scope

Present

file_operation

Operation

message

always

Description: the operation on the file such as UPLOAD/DOWNLOAD. It may contain the suffix 'WARNING', if the operation failed

Example: UPLOAD

Field

Name

Scope

Present

filename

Filename

message

always

Description: the file name

Example: foobar.txt

Field

Name

Scope

Present

filepath

File path

message

always

Description: the path to the file on the server

Example: /tmp

JSON_CIM messages

SessionClosed due to content policy violation

Description of the message: Emitted when content policy with termination action enabled is violated

Example message:

{"verdict":"TERMINATED","vendor":"OneIdentity","user":"root","transport":"tcp","src_user":"gwtestauto","src_port":"57542","src_ip":"10.30.0.24","src":"client.acme.com","session_id":"svc-w6rJcFNZ3c6Bqqu2pAoeoS-my_connection-1","product":"SPS-5.11.0","event_name":"SessionClosed","dvc":"sps1.acme.com","dest_port":"22","dest_ip":"10.170.255.206","dest":"server.acme.com","app":"ssh","_time":"1568984418014"}

The message contains the following fields.

Field

Name

Scope

Present

vendor

Device vendor

product

always

Description: fixed to OneIdentity

Example: OneIdentity

Field

Name

Scope

Present

product

Product version

product

always

Description: short product name with version

Example: SPS-5.11.0

Field

Name

Scope

Present

dvc

Device fqdn

device

always

Description: the hostname of SPS

Example: sps1.acme.com

Field

Name

Scope

Present

session_id

Session ID

session

always

Description: the unique identifier of the session

Example: svc-hjdBxA2UWkTadH3juDVwrT-my_connection-0

Field

Name

Scope

Present

event_name

Event name

message

always

Description: the type of the message

Example: SessionClosed

Field

Name

Scope

Present

_time

Timestamp

message

always

Description: the UNIX time stamp when the event occurred

Example: 1554470652340

Field

Name

Scope

Present

app

Application protocol

session

always

Description: SPS supported protocol

Example: ssh

Field

Name

Scope

Present

dest_ip

Destination address

session

always

Description: the IP address of the server

Example: 10.170.255.206

Field

Name

Scope

Present

dest

Destination host name

session

always

Description: the server hostname or IP address if hostname is not known

Example: server.acme.com

Field

Name

Scope

Present

user

Name of the user

session

always

Description: the server username

Example: root

Field

Name

Scope

Present

dest_port

Destination port

session

always

Description: the port number on the server

Example: 22

Field

Name

Scope

Present

src_ip

Source address

session

always

Description: the IP address of the client

Example: 10.30.0.24

Field

Name

Scope

Present

src

Source host name

session

always

Description: the client hostname or IP address if hostname is not known

Example: client.acme.com

Field

Name

Scope

Present

src_user

Source username

session

sometimes

Description: the authenticated gateway username if there was a successful gateway authentication

Example: gwtestauto

Field

Name

Scope

Present

src_port

Source port

session

always

Description: the port number on the client

Example: 38014

Field

Name

Scope

Present

transport

Transport

session

always

Description: the layer 3 protocol

Example: tcp

Field

Name

Scope

Present

verdict

Verdict

session

always

Description: describes how the session ended, e.g. ACCEPT, AUTH_FAIL, DENY, FAIL, TERMINATED

Example: TERMINATED

ChannelAlert triggered

Description of the message: Emitted when channel alert triggered by content policy

Example message:

{"vendor":"OneIdentity","user":"root","transport":"tcp","subject":"PatternMatcherRule","src_user":"gwtestauto","src_port":"57542","src_ip":"10.30.0.24","src":"client.acme.com","session_id":"svc-w6rJcFNZ3c6Bqqu2pAoeoS-my_connection-1","product":"SPS-5.11.0","matched_regexp":"free","event_name":"ChannelAlert","dvc":"sps1.acme.com","dest_port":"22","dest_ip":"10.170.255.206","dest":"server.acme.com","app":"ssh","alerting_type":"Full screen content","_time":"1568984413910"}

The message contains the following fields.

Field

Name

Scope

Present

vendor

Device vendor

product

always

Description: fixed to OneIdentity

Example: OneIdentity

Field

Name

Scope

Present

product

Product version

product

always

Description: short product name with version

Example: SPS-5.11.0

Field

Name

Scope

Present

transport

Transport

session

always

Description: the layer 3 protocol

Example: tcp

Field

Name

Scope

Present

_time

Timestamp

message

always

Description: the UNIX time stamp when the event occurred

Example: 1554470652340

Field

Name

Scope

Present

session_id

Session ID

session

always

Description: the unique identifier of the session

Example: svc-hjdBxA2UWkTadH3juDVwrT-my_connection-0

Field

Name

Scope

Present

app

Application protocol

session

always

Description: SPS supported protocol

Example: ssh

Field

Name

Scope

Present

src_user

Source username

session

sometimes

Description: the authenticated gateway username if there was a successful gateway authentication

Example: gwtestauto

Field

Name

Scope

Present

src_port

Source port

session

always

Description: the port number on the client

Example: 38014

Field

Name

Scope

Present

src_ip

Source address

session

always

Description: the IP address of the client

Example: 10.30.0.24

Field

Name

Scope

Present

src

Source host name

session

always

Description: the client hostname or IP address if hostname is not known

Example: client.acme.com

Field

Name

Scope

Present

matched_regexp

Matched regexp

message

sometimes

Description: the regexp matching the content that triggered the alert

Example: sudo

Field

Name

Scope

Present

event_name

Event name

message

always

Description: the type of the message

Example: ChannelAlert

Field

Name

Scope

Present

dvc

Device fqdn

device

always

Description: the hostname of SPS

Example: sps1.acme.com

Field

Name

Scope

Present

dest_port

Destination port

session

always

Description: the port number on the server

Example: 22

Field

Name

Scope

Present

dest_ip

Destination address

session

always

Description: the IP address of the server

Example: 10.170.255.206

Field

Name

Scope

Present

dest

Destination host name

session

always

Description: the server hostname or IP address if hostname is not known

Example: server.acme.com

Field

Name

Scope

Present

user

Name of the user

session

always

Description: the server username

Example: root

Field

Name

Scope

Present

alerting_type

Event type

message

sometimes

Description: the type of the event triggering the alert e.g. Command, Full screen content

Example: Command

Field

Name

Scope

Present

subject

Reason

message

sometimes

Description: the rule triggering alert

Example: PatternMatcherRule

ServerConnect on initial contact

Description of the message: Emitted when SPS connects to the serverfor the first time in the session

Example message:

{"vendor":"OneIdentity","user":"","transport":"tcp","src_user":"gwtestauto","src_port":"58140","src_ip":"10.30.0.24","src":"client.acme.com","session_id":"svc-iiCfsG48oJG5smpuocBLAN-my_connection-39","product":"SPS-5.11.0","event_name":"ServerConnect","dvc":"sps1.acme.com","dest_port":"22","dest_ip":"10.170.255.206","dest":"server.acme.com","app":"ssh","action":"added","_time":"1557913195000"}

The message contains the following fields.

Field

Name

Scope

Present

vendor

Device vendor

product

always

Description: fixed to OneIdentity

Example: OneIdentity

Field

Name

Scope

Present

product

Product version

product

always

Description: short product name with version

Example: SPS-5.11.0

Field

Name

Scope

Present

dvc

Device fqdn

device

always

Description: the hostname of SPS

Example: sps1.acme.com

Field

Name

Scope

Present

session_id

Session ID

session

always

Description: the unique identifier of the session

Example: svc-hjdBxA2UWkTadH3juDVwrT-my_connection-0

Field

Name

Scope

Present

event_name

Event name

message

always

Description: the type of the message

Example: ServerConnect

Field

Name

Scope

Present

action

Action

message

always

Description: the taken by the device according to CIM model

Example: added

Field

Name

Scope

Present

_time

Timestamp

message

always

Description: the UNIX time stamp when the event occurred

Example: 1554470652340

Field

Name

Scope

Present

app

Application protocol

session

always

Description: SPS supported protocol

Example: ssh

Field

Name

Scope

Present

dest_ip

Destination address

session

always

Description: the IP address of the server

Example: 10.170.255.206

Field

Name

Scope

Present

dest

Destination host name

session

always

Description: the server hostname or IP address if hostname is not known

Example: server.acme.com

Field

Name

Scope

Present

user

Name of the user

message

always

Description: empty, not known in this message type

Example:

Field

Name

Scope

Present

dest_port

Destination port

session

always

Description: the port number on the server

Example: 22

Field

Name

Scope

Present

src_ip

Source address

session

always

Description: the IP address of the client

Example: 10.30.0.24

Field

Name

Scope

Present

src

Source host name

session

always

Description: the client hostname or IP address if hostname is not known

Example: client.acme.com

Field

Name

Scope

Present

src_user

Source username

session

sometimes

Description: the authenticated gateway username if there was a successful gateway authentication

Example: gwtestauto

Field

Name

Scope

Present

src_port

Source port

session

always

Description: the port number on the client

Example: 38014

Field

Name

Scope

Present

transport

Transport

session

always

Description: the layer 3 protocol

Example: tcp

ServerConnect for secondary channels

Description of the message: Emitted when SPS connects to the serverfor opening further channels. The difference from initial connection is that the server user name is known and authenticated this time.

Example message:

{"vendor":"OneIdentity","user":"","transport":"tcp","src_user":"gwtestauto","src_port":"58140","src_ip":"10.30.0.24","src":"client.acme.com","user":"root","session_id":"svc-iiCfsG48oJG5smpuocBLAN-my_connection-39","product":"SPS-5.11.0","event_name":"ServerConnect","dvc":"sps1.acme.com","dest_port":"22","dest_ip":"10.170.255.206","dest":"server.acme.com","app":"ssh","action":"added","_time":"1557913195000"}

The message contains the following fields.

Field

Name

Scope

Present

vendor

Device vendor

product

always

Description: fixed to OneIdentity

Example: OneIdentity

Field

Name

Scope

Present

product

Product version

product

always

Description: short product name with version

Example: SPS-5.11.0

Field

Name

Scope

Present

dvc

Device fqdn

device

always

Description: the hostname of SPS

Example: sps1.acme.com

Field

Name

Scope

Present

session_id

Session ID

session

always

Description: the unique identifier of the session

Example: svc-hjdBxA2UWkTadH3juDVwrT-my_connection-0

Field

Name

Scope

Present

event_name

Event name

message

always

Description: the type of the message

Example: ServerConnect

Field

Name

Scope

Present

action

Action

message

always

Description: the taken by the device according to CIM model

Example: added

Field

Name

Scope

Present

_time

Timestamp

message

always

Description: the UNIX time stamp when the event occurred

Example: 1554470652340

Field

Name

Scope

Present

app

Application protocol

session

always

Description: SPS supported protocol

Example: ssh

Field

Name

Scope

Present

dest_ip

Destination address

session

always

Description: the IP address of the server

Example: 10.170.255.206

Field

Name

Scope

Present

dest

Destination host name

session

always

Description: the server hostname or IP address if hostname is not known

Example: server.acme.com

Field

Name

Scope

Present

user

Name of the user

session

always

Description: the server username

Example: root

Field

Name

Scope

Present

dest_port

Destination port

session

always

Description: the port number on the server

Example: 22

Field

Name

Scope

Present

src_ip

Source address

session

always

Description: the IP address of the client

Example: 10.30.0.24

Field

Name

Scope

Present

src

Source host name

session

always

Description: the client hostname or IP address if hostname is not known

Example: client.acme.com

Field

Name

Scope

Present

src_user

Source username

session

sometimes

Description: the authenticated gateway username if there was a successful gateway authentication

Example: gwtestauto

Field

Name

Scope

Present

src_port

Source port

session

always

Description: the port number on the client

Example: 38014

Field

Name

Scope

Present

transport

Transport

session

always

Description: the layer 3 protocol

Example: tcp

ServerAuthenticationSuccess

Description of the message: Emitted after the server authentication successfully happened

Example message:

{"vendor":"OneIdentity","user":"root","transport":"tcp","src_user":"gwtestauto","src_port":"57982","src_ip":"10.30.0.24","src":"client.acme.com","session_id":"svc-iiCfsG48oJG5smpuocBLAN-my_connection-38","product":"SPS-5.11.0","event_name":"ServerAuthenticationSuccess","dvc":"sps1.acme.com","dest_port":"22","dest_ip":"10.170.255.206","dest":"server.acme.com","app":"ssh","action":"success","_time":"1557913189329"}

The message contains the following fields.

Field

Name

Scope

Present

vendor

Device vendor

product

always

Description: fixed to OneIdentity

Example: OneIdentity

Field

Name

Scope

Present

product

Product version

product

always

Description: short product name with version

Example: SPS-5.11.0

Field

Name

Scope

Present

dvc

Device fqdn

device

always

Description: the hostname of SPS

Example: sps1.acme.com

Field

Name

Scope

Present

session_id

Session ID

session

always

Description: the unique identifier of the session

Example: svc-hjdBxA2UWkTadH3juDVwrT-my_connection-0

Field

Name

Scope

Present

event_name

Event name

message

always

Description: the type of the message

Example: ServerAuthenticationSuccess

Field

Name

Scope

Present

action

Action

message

always

Description: marks a successful authentication

Example: success

Field

Name

Scope

Present

_time

Timestamp

message

always

Description: the UNIX time stamp when the event occurred

Example: 1554470652340

Field

Name

Scope

Present

app

Application protocol

session

always

Description: SPS supported protocol

Example: ssh

Field

Name

Scope

Present

dest_ip

Destination address

session

always

Description: the IP address of the server

Example: 10.170.255.206

Field

Name

Scope

Present

dest

Destination host name

session

always

Description: the server hostname or IP address if hostname is not known

Example: server.acme.com

Field

Name

Scope

Present

user

Name of the user

session

always

Description: the server username

Example: root

Field

Name

Scope

Present

dest_port

Destination port

session

always

Description: the port number on the server

Example: 22

Field

Name

Scope

Present

src_ip

Source address

session

always

Description: the IP address of the client

Example: 10.30.0.24

Field

Name

Scope

Present

src

Source host name

session

always

Description: the client hostname or IP address if hostname is not known

Example: client.acme.com

Field

Name

Scope

Present

src_user

Source username

session

sometimes

Description: the authenticated gateway username if there was a successful gateway authentication

Example: gwtestauto

Field

Name

Scope

Present

src_port

Source port

session

always

Description: the port number on the client

Example: 38014

Field

Name

Scope

Present

transport

Transport

session

always

Description: the layer 3 protocol

Example: tcp

ServerAuthenticationFailure

Description of the message: Emitted after the server authentication failed

Example message:

{"vendor":"OneIdentity","user":"root","transport":"tcp","src_user":"gwtestauto","src_port":"58140","src_ip":"10.30.0.24","src":"client.acme.com","session_id":"svc-iiCfsG48oJG5smpuocBLAN-my_connection-39","product":"SPS-5.11.0","event_name":"ServerAuthenticationFailure","dvc":"sps1.acme.com","dest_port":"22","dest_ip":"10.170.255.206","dest":"server.acme.com","app":"ssh","action":"failure","_time":"1557913197211"}

The message contains the following fields.

Field

Name

Scope

Present

vendor

Device vendor

product

always

Description: fixed to OneIdentity

Example: OneIdentity

Field

Name

Scope

Present

product

Product version

product

always

Description: short product name with version

Example: SPS-5.11.0

Field

Name

Scope

Present

dvc

Device fqdn

device

always

Description: the hostname of SPS

Example: sps1.acme.com

Field

Name

Scope

Present

session_id

Session ID

session

always

Description: the unique identifier of the session

Example: svc-hjdBxA2UWkTadH3juDVwrT-my_connection-0

Field

Name

Scope

Present

event_name

Event name

message

always

Description: the type of the message

Example: ServerAuthenticationFailure

Field

Name

Scope

Present

action

Action

message

always

Description: marks a failed authentication

Example: failure

Field

Name

Scope

Present

_time

Timestamp

message

always

Description: the UNIX time stamp when the event occurred

Example: 1554470652340

Field

Name

Scope

Present

app

Application protocol

session

always

Description: SPS supported protocol

Example: ssh

Field

Name

Scope

Present

dest_ip

Destination address

session

always

Description: the IP address of the server

Example: 10.170.255.206

Field

Name

Scope

Present

dest

Destination host name

session

always

Description: the server hostname or IP address if hostname is not known

Example: server.acme.com

Field

Name

Scope

Present

user

Name of the user

session

always

Description: contains the non authenticated server username

Example: root

Field

Name

Scope

Present

dest_port

Destination port

session

always

Description: the port number on the server

Example: 22

Field

Name

Scope

Present

src_ip

Source address

session

always

Description: the IP address of the client

Example: 10.30.0.24

Field

Name

Scope

Present

src

Source host name

session

always

Description: the client hostname or IP address if hostname is not known

Example: client.acme.com

Field

Name

Scope

Present

src_user

Source username

session

sometimes

Description: the authenticated gateway username if there was a successful gateway authentication

Example: gwtestauto

Field

Name

Scope

Present

src_port

Source port

session

always

Description: the port number on the client

Example: 38014

Field

Name

Scope

Present

transport

Transport

session

always

Description: the layer 3 protocol

Example: tcp

GatewayAuthenticationFailure

Description of the message: Emitted after a failed gateway authentication. Note that the gateway username here is not authenticated and will not be retained in further messages to avoid confusion with an authenticated gateway user.

Example message:

{"vendor":"OneIdentity","user":"","transport":"tcp","src_user":"gwtestauto","src_port":"49070","src_ip":"10.30.0.24","src":"client.acme.com","session_id":"svc-mBbMWzauBWHQN9TpoZz8mD-my_connection-15","product":"SPS-5.11.0","event_name":"GatewayAuthenticationFailure","dvc":"sps1.acme.com","dest_port":"","dest_ip":"","dest":"","app":"ssh","action":"failure","_time":"1557912792360"}

The message contains the following fields.

Field

Name

Scope

Present

vendor

Device vendor

product

always

Description: fixed to OneIdentity

Example: OneIdentity

Field

Name

Scope

Present

product

Product version

product

always

Description: short product name with version

Example: SPS-5.11.0

Field

Name

Scope

Present

dvc

Device fqdn

device

always

Description: the hostname of SPS

Example: sps1.acme.com

Field

Name

Scope

Present

session_id

Session ID

session

always

Description: the unique identifier of the session

Example: svc-hjdBxA2UWkTadH3juDVwrT-my_connection-0

Field

Name

Scope

Present

event_name

Event name

message

always

Description: the type of the message

Example: GatewayAuthenticationFailure

Field

Name

Scope

Present

action

Action

message

always

Description: marks a failed authentication

Example: failure

Field

Name

Scope

Present

dest

Destination host name

session

always

Description: empty, not known in this message type

Example:

Field

Name

Scope

Present

dest_ip

Destination address

session

always

Description: empty, not known in this message type

Example:

Field

Name

Scope

Present

user

Name of the user

message

always

Description: empty, not known in this message type

Example:

Field

Name

Scope

Present

dest_port

Destination port

session

always

Description: empty, not known in this message type

Example:

Field

Name

Scope

Present

_time

Timestamp

message

always

Description: the UNIX time stamp when the event occurred

Example: 1554470652340

Field

Name

Scope

Present

app

Application protocol

session

always

Description: SPS supported protocol

Example: ssh

Field

Name

Scope

Present

src_ip

Source address

session

always

Description: the IP address of the client

Example: 10.30.0.24

Field

Name

Scope

Present

src

Source host name

session

always

Description: the client hostname or IP address if hostname is not known

Example: client.acme.com

Field

Name

Scope

Present

src_user

Source username

message

always

Description: the non authenticated gateway username

Example: gwtestauto

Field

Name

Scope

Present

src_port

Source port

session

always

Description: the port number on the client

Example: 38014

Field

Name

Scope

Present

transport

Transport

session

always

Description: the layer 3 protocol

Example: tcp

SessionClosed of successfully authenticated session

Description of the message: Emitted when the session ends and server authentication and any gateway authentication was successful. There may be further messages related to the session after this message due to post processing of session data!

Example message:

{"vendor":"OneIdentity","user":"root","transport":"tcp","src_user":"gwtestauto","src_port":"48302","src_ip":"10.30.0.24","src":"client.acme.com","session_id":"svc-mBbMWzauBWHQN9TpoZz8mD-my_connection-12","product":"SPS-5.11.0","event_name":"SessionClosed","dvc":"sps1.acme.com","verdict":"ACCEPT","dest_port":"22","dest_ip":"10.170.255.206","dest":"server.acme.com","app":"ssh","_time":"1557912765545"}

The message contains the following fields.

Field

Name

Scope

Present

vendor

Device vendor

product

always

Description: fixed to OneIdentity

Example: OneIdentity

Field

Name

Scope

Present

product

Product version

product

always

Description: short product name with version

Example: SPS-5.11.0

Field

Name

Scope

Present

dvc

Device fqdn

device

always

Description: the hostname of SPS

Example: sps1.acme.com

Field

Name

Scope

Present

session_id

Session ID

session

always

Description: the unique identifier of the session

Example: svc-hjdBxA2UWkTadH3juDVwrT-my_connection-0

Field

Name

Scope

Present

event_name

Event name

message

always

Description: the type of the message

Example: SessionClosed

Field

Name

Scope

Present

_time

Timestamp

message

always

Description: the UNIX time stamp when the event occurred

Example: 1554470652340

Field

Name

Scope

Present

app

Application protocol

session

always

Description: SPS supported protocol

Example: ssh

Field

Name

Scope

Present

dest_ip

Destination address

session

always

Description: the IP address of the server

Example: 10.170.255.206

Field

Name

Scope

Present

dest

Destination host name

session

always

Description: the server hostname or IP address if hostname is not known

Example: server.acme.com

Field

Name

Scope

Present

user

Name of the user

session

always

Description: the server username

Example: root

Field

Name

Scope

Present

dest_port

Destination port

session

always

Description: the port number on the server

Example: 22

Field

Name

Scope

Present

src_ip

Source address

session

always

Description: the IP address of the client

Example: 10.30.0.24

Field

Name

Scope

Present

src

Source host name

session

always

Description: the client hostname or IP address if hostname is not known

Example: client.acme.com

Field

Name

Scope

Present

src_user

Source username

session

sometimes

Description: the authenticated gateway username if there was a successful gateway authentication

Example: gwtestauto

Field

Name

Scope

Present

src_port

Source port

session

always

Description: the port number on the client

Example: 38014

Field

Name

Scope

Present

transport

Transport

session

always

Description: the layer 3 protocol

Example: tcp

Field

Name

Scope

Present

verdict

Verdict

session

always

Description: describes how the session ended, e.g. ACCEPT, AUTH_FAIL, DENY, FAIL, TERMINATED

Example: ACCEPT

SessionClosed after a failed gateway authentication

Description of the message: Emitted when the session ends because gateway authentication failed.

Example message:

{"vendor":"OneIdentity","user":"","transport":"tcp","src_user":"","src_port":"49070","src_ip":"10.30.0.24","src":"client.acme.com","session_id":"svc-mBbMWzauBWHQN9TpoZz8mD-my_connection-15","product":"SPS-5.11.0","event_name":"SessionClosed","dvc":"sps1.acme.com","dest_port":"","dest_ip":"","dest":"","app":"ssh","_time":"1557912792398","verdict":"AUTH_FAIL"}

The message contains the following fields.

Field

Name

Scope

Present

vendor

Device vendor

product

always

Description: fixed to OneIdentity

Example: OneIdentity

Field

Name

Scope

Present

product

Product version

product

always

Description: short product name with version

Example: SPS-5.11.0

Field

Name

Scope

Present

dvc

Device fqdn

device

always

Description: the hostname of SPS

Example: sps1.acme.com

Field

Name

Scope

Present

session_id

Session ID

session

always

Description: the unique identifier of the session

Example: svc-hjdBxA2UWkTadH3juDVwrT-my_connection-0

Field

Name

Scope

Present

event_name

Event name

message

always

Description: the type of the message

Example: SessionClosed

Field

Name

Scope

Present

_time

Timestamp

message

always

Description: the UNIX time stamp when the event occurred

Example: 1554470652340

Field

Name

Scope

Present

app

Application protocol

session

always

Description: SPS supported protocol

Example: ssh

Field

Name

Scope

Present

dest_ip

Destination address

session

always

Description: empty, not known in this message type

Example:

Field

Name

Scope

Present

dest

Destination host name

session

always

Description: empty, not known in this message type

Example:

Field

Name

Scope

Present

user

Name of the user

message

always

Description: empty, not known in this message type

Example:

Field

Name

Scope

Present

dest_port

Destination port

session

always

Description: empty, not known in this message type

Example:

Field

Name

Scope

Present

src_ip

Source address

session

always

Description: the IP address of the client

Example: 10.30.0.24

Field

Name

Scope

Present

src

Source host name

session

always

Description: the client hostname or IP address if hostname is not known

Example: client.acme.com

Field

Name

Scope

Present

src_user

Source username

session

always

Description: empty, not known in this message type

Example:

Field

Name

Scope

Present

src_port

Source port

session

always

Description: the port number on the client

Example: 38014

Field

Name

Scope

Present

transport

Transport

session

always

Description: the layer 3 protocol

Example: tcp

Field

Name

Scope

Present

verdict

Verdict

session

always

Description: describes how the session ended, e.g. ACCEPT, AUTH_FAIL, DENY, FAIL, TERMINATED

Example: AUTH_FAIL

SessionClosed after a failed server authentication

Description of the message: Emitted when the session ends because server authentication failed.

Example message:

{"vendor":"OneIdentity","user":"","transport":"tcp","src_user":"gwtestauto","src_port":"49426","src_ip":"10.30.0.24","src":"client.acme.com","session_id":"svc-mBbMWzauBWHQN9TpoZz8mD-my_connection-17","product":"SPS-5.11.0","event_name":"SessionClosed","dvc":"sps1.acme.com","dest_port":"22","verdict":"AUTH_FAIL","dest_ip":"10.170.255.206","dest":"server.acme.com","app":"ssh","_time":"1557912813792"}

The message contains the following fields.

Field

Name

Scope

Present

vendor

Device vendor

product

always

Description: fixed to OneIdentity

Example: OneIdentity

Field

Name

Scope

Present

product

Product version

product

always

Description: short product name with version

Example: SPS-5.11.0

Field

Name

Scope

Present

dvc

Device fqdn

device

always

Description: the hostname of SPS

Example: sps1.acme.com

Field

Name

Scope

Present

session_id

Session ID

session

always

Description: the unique identifier of the session

Example: svc-hjdBxA2UWkTadH3juDVwrT-my_connection-0

Field

Name

Scope

Present

event_name

Event name

message

always

Description: the type of the message

Example: SessionClosed

Field

Name

Scope

Present

_time

Timestamp

message

always

Description: the UNIX time stamp when the event occurred

Example: 1554470652340

Field

Name

Scope

Present

app

Application protocol

session

always

Description: SPS supported protocol

Example: ssh

Field

Name

Scope

Present

dest_ip

Destination address

session

always

Description: the IP address of the server

Example: 10.170.255.206

Field

Name

Scope

Present

dest

Destination host name

session

always

Description: the server hostname or IP address if hostname is not known

Example: server.acme.com

Field

Name

Scope

Present

user

Name of the user

message

always

Description: empty, not known in this message type

Example:

Field

Name

Scope

Present

dest_port

Destination port

session

always

Description: the port number on the server

Example: 22

Field

Name

Scope

Present

src_ip

Source address

session

always

Description: the IP address of the client

Example: 10.30.0.24

Field

Name

Scope

Present

src

Source host name

session

always

Description: the client hostname or IP address if hostname is not known

Example: client.acme.com

Field

Name

Scope

Present

src_user

Source username

session

sometimes

Description: the authenticated gateway username if there was a successful gateway authentication

Example: gwtestauto

Field

Name

Scope

Present

src_port

Source port

session

always

Description: the port number on the client

Example: 38014

Field

Name

Scope

Present

transport

Transport

session

always

Description: the layer 3 protocol

Example: tcp

Field

Name

Scope

Present

verdict

Verdict

session

always

Description: describes how the session ended, e.g. ACCEPT, AUTH_FAIL, DENY, FAIL, TERMINATED

Example: AUTH_FAIL

RdpEmbeddedInTsg

Description of the message: Emitted when the gateway user is acquired in a Terminal Service Gateway authentication scenario.

Example message:

{"vendor":"OneIdentity","user":"","transport":"tcp","src_user":"gwtestauto","src_port":"51204","src_ip":"10.30.0.24","src":"client.acme.com","session_id":"svc-oUDm7arcL8zNb3t2CVwSQr-my_connection-47-4","product":"SPS-5.11.0","event_name":"RdpEmbeddedInTsg","dvc":"sps1.acme.com","dest_port":"","dest_ip":"","dest":"","app":"rdp","action":"allowed","_time":"1558006936608"}

The message contains the following fields.

Field

Name

Scope

Present

vendor

Device vendor

product

always

Description: fixed to OneIdentity

Example: OneIdentity

Field

Name

Scope

Present

product

Product version

product

always

Description: short product name with version

Example: SPS-5.11.0

Field

Name

Scope

Present

dvc

Device fqdn

device

always

Description: the hostname of SPS

Example: sps1.acme.com

Field

Name

Scope

Present

session_id

Session ID

session

always

Description: the unique identifier of the session

Example: svc-hjdBxA2UWkTadH3juDVwrT-my_connection-0

Field

Name

Scope

Present

event_name

Event name

message

always

Description: the type of the message

Example: RdpEmbeddedInTsg

Field

Name

Scope

Present

action

Action

message

always

Description: the action taken by the device according to CIM model

Example: allowed

Field

Name

Scope

Present

_time

Timestamp

message

always

Description: the UNIX time stamp when the event occurred

Example: 1554470652340

Field

Name

Scope

Present

app

Application protocol

session

always

Description: SPS supported protocol

Example: ssh

Field

Name

Scope

Present

dest_ip

Destination address

session

always

Description: empty, not known in this message type

Example:

Field

Name

Scope

Present

dest

Destination host name

session

always

Description: empty, not known in this message type

Example:

Field

Name

Scope

Present

user

Name of the user

message

always

Description: empty, not known in this message type

Example:

Field

Name

Scope

Present

dest_port

Destination port

session

always

Description: empty, not known in this message type

Example:

Field

Name

Scope

Present

src_ip

Source address

session

always

Description: the IP address of the client

Example: 10.30.0.24

Field

Name

Scope

Present

src

Source host name

session

always

Description: the client hostname or IP address if hostname is not known

Example: client.acme.com

Field

Name

Scope

Present

src_user

Source username

session

always

Description: the authenticated gateway username

Example: gwtestauto

Field

Name

Scope

Present

src_port

Source port

session

always

Description: the port number on the client

Example: 38014

Field

Name

Scope

Present

transport

Transport

session

always

Description: the layer 3 protocol

Example: tcp

SessionScored

Description of the message: Score messages represent scoring events when SPS has calculated an initial or changed score for the session.

Example message:

{"vendor":"OneIdentity","signature":"keystroke","session_id":"svc-416YVFZMy7rT8RA7T7yeAs-my_connection-0","product":"SPS-5.11.0","event_name":"SessionScored","dvc":"sps1.acme.com","algorithm_score":"18","algorithm_name":"keystroke","aggregated_score":"70","action":"allowed","_time":"1558010880806"}

The message contains the following fields.

Field

Name

Scope

Present

vendor

Device vendor

product

always

Description: fixed to OneIdentity

Example: OneIdentity

Field

Name

Scope

Present

product

Product version

product

always

Description: short product name with version

Example: SPS-5.11.0

Field

Name

Scope

Present

dvc

Device fqdn

device

always

Description: the hostname of SPS

Example: sps1.acme.com

Field

Name

Scope

Present

session_id

Session ID

session

always

Description: the unique identifier of the session

Example: svc-hjdBxA2UWkTadH3juDVwrT-my_connection-0

Field

Name

Scope

Present

event_name

Event name

message

always

Description: the type of the message

Example: SessionScored

Field

Name

Scope

Present

action

Action

message

always

Description: the action taken by the device according to CIM model

Example: allowed

Field

Name

Scope

Present

_time

Timestamp

message

always

Description: the UNIX time stamp when the event occurred

Example: 1554470652340

Field

Name

Scope

Present

aggregated_score

Aggregated score

message

always

Description: the average score from all enabled analytics algorithms

Example: 50

Field

Name

Scope

Present

algorithm_name

Algorithm name

message

always

Description: the name of the algorithm that changed value

Example: keystroke

Field

Name

Scope

Present

signature

Signature

message

always

Description: the algorithm name as CIM intrusion detection signature

Example: hostlogin

Field

Name

Scope

Present

algorithm_score

Algorithm score

message

always

Description: the new score value of the algorithm that changed value

Example: 60

CommandChannelEvent

Description of the message: Emitted when a command is detected in the session channel text.

Example message:

{"vendor":"OneIdentity","session_id":"svc-mBbMWzauBWHQN9TpoZz8mD-my_connection-12","product":"SPS-5.11.0","event_name":"CommandChannelEvent","dvc":"sps1.acme.com","command":"exit","action":"allowed","_time":"1557912765461"}

The message contains the following fields.

Field

Name

Scope

Present

vendor

Device vendor

product

always

Description: fixed to OneIdentity

Example: OneIdentity

Field

Name

Scope

Present

product

Product version

product

always

Description: short product name with version

Example: SPS-5.11.0

Field

Name

Scope

Present

dvc

Device fqdn

device

always

Description: the hostname of SPS

Example: sps1.acme.com

Field

Name

Scope

Present

session_id

Session ID

session

always

Description: the unique identifier of the session

Example: svc-hjdBxA2UWkTadH3juDVwrT-my_connection-0

Field

Name

Scope

Present

event_name

Event name

message

always

Description: the type of the message

Example: CommandChannelEvent

Field

Name

Scope

Present

action

Action

message

always

Description: the action taken by the device according to CIM model

Example: allowed

Field

Name

Scope

Present

_time

Timestamp

message

always

Description: the UNIX time stamp when the event occurred

Example: 1554470652340

Field

Name

Scope

Present

command

Command

message

always

Description: the full command detected

Example: exit

WindowTitleChannelEvent

Description of the message: Emitted when a command is detected in the session channel text.

Example message:

{"window_title":"Shortcut Tools Application Tools Administrative Tools","vendor":"OneIdentity","session_id":"svc-oUDm7arcL8zNb3t2CVwSQr-my_connection-47-4","product":"SPS-5.11.0","event_name":"WindowTitleChannelEvent","dvc":"sps1.acme.com","action":"allowed","_time":"1558007001482"}

The message contains the following fields.

Field

Name

Scope

Present

vendor

Device vendor

product

always

Description: fixed to OneIdentity

Example: OneIdentity

Field

Name

Scope

Present

product

Product version

product

always

Description: short product name with version

Example: SPS-5.11.0

Field

Name

Scope

Present

dvc

Device fqdn

device

always

Description: the hostname of SPS

Example: sps1.acme.com

Field

Name

Scope

Present

session_id

Session ID

session

always

Description: the unique identifier of the session

Example: svc-hjdBxA2UWkTadH3juDVwrT-my_connection-0

Field

Name

Scope

Present

event_name

Event name

message

always

Description: the type of the message

Example: WindowTitleChannelEvent

Field

Name

Scope

Present

action

Action

message

always

Description: the action taken by the device according to CIM model

Example: allowed

Field

Name

Scope

Present

_time

Timestamp

message

always

Description: the UNIX time stamp when the event occurred

Example: 1554470652340

Field

Name

Scope

Present

window_title

Window title

message

always

Description: the window title detected in graphical protocol

Example: firefox

FileTransfer

Description of the message: Emitted when a command is detected in the session channel text.

Example message:

{"vendor":"OneIdentity","session_id":"svc-2L83Phh9J6GKLWTc881awk-my_connection-324","product":"SPS-5.11.0","file_path":"/cpuinfo","file_operation":"UPLOAD","file_name":"cpuinfo","event_name":"FileTransfer","dvc":"sps1.acme.com","action":"allowed","_time":"1558023721326"}

The message contains the following fields.

Field

Name

Scope

Present

vendor

Device vendor

product

always

Description: fixed to OneIdentity

Example: OneIdentity

Field

Name

Scope

Present

product

Product version

product

always

Description: short product name with version

Example: SPS-5.11.0

Field

Name

Scope

Present

dvc

Device fqdn

device

always

Description: the hostname of SPS

Example: sps1.acme.com

Field

Name

Scope

Present

session_id

Session ID

session

always

Description: the unique identifier of the session

Example: svc-hjdBxA2UWkTadH3juDVwrT-my_connection-0

Field

Name

Scope

Present

event_name

Event name

message

always

Description: the type of the message

Example: FileTransfer

Field

Name

Scope

Present

action

Action

message

always

Description: the action taken by the device according to CIM model

Example: allowed

Field

Name

Scope

Present

_time

Timestamp

message

always

Description: the UNIX time stamp when the event occurred

Example: 1554470652340

Field

Name

Scope

Present

file_operation

Operation

message

always

Description: the operation on the file such as UPLOAD/DOWNLOAD. It may contain the suffix 'WARNING', if the operation failed

Example: UPLOAD

Field

Name

Scope

Present

file_name

Filename

message

always

Description: the file name

Example: foobar.txt

Field

Name

Scope

Present

file_path

Full file path

message

always

Description: the name of the file including its path on the server (in case of RDP protocol, this field is empty, in this case the full path of the file is in the filename field)

Example: /tmp/foobar.txt

Starling integration

One Identity Starling helps to combine products from the One Identity line to create a secure and customizable cloud service. For more information, see the Starling technical documentation.

If you are using a Starling 2FA plugin, (that is, you have uploaded it to Basic Settings > Plugins and then configured it at Policies > AA Plugin Configurations) and the SPS node is joined to One Identity Starling, you do not have to specify api_key and api_url in the Starling 2FA plugin configuration. This configuration method is more secure.

Topics:

Joining SPS to One Identity Starling

This section describes how to use SPS with One Identity Starling and how to take advantage of companion features from Starling products, such as Two-Factor Authentication (2FA) and Identity Analytics.

Prerequisites
  • An existing Starling organization (tenant).

    NOTE: Consider the following:

    • If you have several Starling organizations, you can join your SPS to any of the existing organizations. However, ensure that you remember the Starling organization you joined to your SPS. This might be required if there is a join failure and you need to unjoin SPS from the respective Starling organization.

    • To use Starling with SPS, you need a Starling organization and account within a United States or a European Union data center. Note that if you want to use Starling 2FA, you must use a United States data center (European Union data center is not yet supported).

To join SPS to One Identity Starling

  1. Navigate to Basic Settings > Starling Integration.

    CAUTION: If SPS nodes are joined to a cluster, ensure that you initiate your Starling integration from the Central Management node.

  2. To check the availability of SPS and Starling, that is, if SPS can connect directly to the web and SPS can access Starling, click Check availability.

    • If your SPS cannot connect directly to the web, check your Internet connection and ensure that SPS can connect to the web, then re-initiate the process of joining your SPS to Starling. Ensure that SPS can access the following websites:

      • account.cloud.oneidentity.com

      • sts.cloud.oneidentity.com

      • accountsupervisor.cloud.oneidentity.com

      • oneidentitycloud.statuspage.io

      If your SPS is behind a web proxy, navigate to Basic Settings > Network > HTTPS Proxy and configure the proxy settings.

      For more information, see Network settings.

      NOTE: Currently, only built-in Certificate Authorities are supported. If the web proxy replaces the certificates of the Starling website on-the-fly, the join process might fail.

    • If SPS cannot access Starling, wait until Starling is available and re-initiate the process of joining your SPS to Starling.

    Figure 76: Basic Settings > Starling IntegrationSPS is ready to join Starling

    Starling ready to join

  3. When SPS is ready to join Starling, click Start join.

    The One Identity Starling site will open on a new tab.

    NOTE: Once you click Start join, you cannot stop the process and your SPS machine will be joined to Starling. Ensure that you continue with the join process, and once the join process is complete, if required, you can unjoin SPS from Starling.

    For more information, see Unjoining SPS from One Identity Starling.

  4. To allow SPS to access your Starling organization and the services that you have subscribed to, click Allow.

    The Join to Starling screen is displayed.

    Figure 77: Basic Settings > Starling Integration — Example of SPS joined to Starling

    SPS joined to Starling

Result

Your SPS instance is joined to Starling.

Related Documents

The document was helpful.

Select Rating

I easily found the information I needed.

Select Rating
